Ziton ZP3-AB-SCB-D Repeater driver board
SKU
48202
£227.39 £189.49
Ziton ZP3-AB-SCB-D Repeater driver board
The Ziton ZP3AB-SCB-D serial control bus driver is attached directly onto the ZP3 main control board inside the panel enclosure. It provides the means to connect and operate from 1 to 32 remote display units (ZP3-RDUB1) and or remote control units (ZP3AB-SCB-R), enabling repeat indication and system control, at locations remote from the main panel position.
Comms operates by RS485 protocol over twisted screened pair wiring. The Driver can be added cost effectively to any ZP3 control panel in order to provide extra facilities.
| Key Features |
|---|
| > Optional driver for up to 32 remote display > Housed inside standard panel enclosure > RS485 communication protocol > Flexible wiring connection |
| Manufacturer | Ziton |
|---|---|
| MPN | 48202 |
Write Your Own Review
Sort By:
No questions yet. Be the first to ask the question!
| Code: | 48202 |
| Description: | Ziton ZP3 Series - ZP3AB-SCB-D Bus Driver EN54 |
| Dimensions: | W:55mm x H:120mm |
| Compatibility: | ZP3 control panels |
| Comms ports: | RS485 |
| Current consumption: | 40 mA |
| Wiring: | Two cores twisted screened pair, max cable length 2km for all remote units connected to a ZP3 panel Cable lengths greater than 2km via RS 485 booster or fibre optic connection |
| Operating temperature: | -10 to +60ºC |
| Relative humidity: | 10 to 90% non-condensing |
| Mounting: | PCB, Plug and socket - fixes to allotted space on panel main control board |
| Weight: | 53g |
