SKU
ZP2-AFR-S
£655.48 £546.23
Ziton Addressable Fire Panel Repeater, small cabinet (ZP2-AFR-S)
The Ziton ZP2-AFR-S Fire Repeater Panel comes with a 2010-2A-NB network board already fitted. Except for having no addressable loops and corresponding programmable outputs, the setup is similar as a normal fire panel. It and has its own power supply, 2 conventional relay outputs and 2 supervised outputs, working in pairs and dedicated to common fire and fault conditions, as well as 2 user configurable inputs for monitoring and control.
Key Features |
---|
> Local or global repeater with or without global control functionality > Up to 24 LED zone indicators for Fire and Fault with space for a 4 digit number > Auto configuration, setup wizards and default regional setup modes > Ethernet port with TCP/IP for remote diagnostics, maintenance and programming > EN54 compliant graphical LCD with icons and up to 256 zones > Improved Jog Dial with 4 soft buttons for simple and intuitive user control > Pleasing design with robust painted steel door > Easy removable door and chassis for quick and clean installation > All pluggable connectors > 3 USB ports with memory stick support and RS232 for printer support > 3 operator level menu structure (20 usernames and passwords) > Email notification for events directly from the panel (4 user accounts) > History log memory for 9999 events > Backwards compatible, supporting site retrofit/upgrades, expansions, replacement > Comes standard fitted with network board |
Manufacturer | Ziton |
---|---|
MPN | ZP2-AFR-S |
Write Your Own Review
![Loading...](https://www.safefiredirect.co.uk/static/version1719466362/frontend/Alothemes/electro2s/en_GB/MageArray_ProductQuestions/images/loader.gif)
Sort By:
No questions yet. Be the first to ask the question!
Code: | ZP2-AFR-S |
Description: | Ziton Addressable Fire Panel Repeater, small cabinet |
Dimensions: | W:446mm x H:536mm x D:164mm |
User interface: | Without fire Brigade controls |
Operating voltage: | 110 / 240 VAC (+10%/-15%), 50 / 60 Hz (±5%) Mains supply cable typ: 3 x 1.5 mm² (live, neutral, earth) |
Current consumption: | Nom. 0.6 / 1.3 A, Max. 1.5 A / 3.15 A Fuse rating: 2 / 4 A |
Network size (nodes): | up to 64 |
STANDBY BATTERY | |
Capacity: | Max. 2 x 12 V / 18 Ah (use supplied cables) |
Charging: | 27.3 V at 20ºC ; 36 mV/ºC |
Low battery warning threshold: | 23.6 VDC ± 1% at 25ºC |
Batteries supported in housing: | Max. 2 x 12 V / 7.2 Ah (use supplied cables) |
Mounting type: | Surface |
Operating temperature: | -5 to +40°C |
Storage temperature: | -20 to +50°C |
Relative humidity: | 10 - 95% max. non condensing |
IP rating: | IP30, indoor use only |
Colour: | White (RAL9003) |
Cable entries: | 18 (20mm) / 2 (20mm) / 2 removable plates (Top/Bottom/Back) |
Material: | Steel (painted) |
Regulatory: | CPD, RoHS, WEEE compliant EN54-13, EN54-2, EN54-21, EN54-4 certified |
Weight: | 10.1kg (7.4kg without battery) |
