SKU
DC-9504E
£16.61 £13.84
GST Innovation loop isolator base for GST200 and GST IFP8
- Buy 10 for £16.36 £13.63 each and save 2%
- Buy 20 for £16.09 £13.41 each and save 3%
- Buy 50 for £15.84 £13.20 each and save 5%
The GST DC-9504E is a short circuit loop isolator that provides protection for the addressable loop by isolating the faulty loop segment from the rest of the loop, ensuring continued normal operation of other devices sharing the same cabling.
Key Features |
---|
> Isolates the faulty part of the loop in the event of a short circuit > Supports class-A and class-B loop connections > Can be used as an alternative to a standard base > Automatic reset when the fault is cleared > Integrated LED indicates isolation condition > May be used in stand alone mode with a cover (similar to a stand alone isolator) > Supports the standard remote indicator output for the detector > LPCB marked |
Manufacturer | GST |
---|---|
MPN | DC-9504E |
Write Your Own Review
Sort By:
No questions yet. Be the first to ask the question!
Code: | DC-9504E |
Description: | GST DI-9000E Series Innovation Detector base w/ Isolator |
Dimensions: | 100 x 39mm (Ø x H) |
Status indication: | LED |
Compatibility: | GST DI-9000E series systems |
Addressing method: | No addressing required |
Power supply type: | Loop powered |
Colour: | White |
Mounting type: | Ceiling mount, wall mount |
Cable entries: | 1 |
Vandal proof: | No |
Operating temperature: | -10 to +50°C |
Relative humidity: | <95%, non-condensing |
Environment: | Indoor |
Compatible products: | DI-9101E: GST Intelligent DI-9000E Series Addressable Multisensor (Optical/Heat) DI-9102E: GST Intelligent DI-9000E Series Addressable Optical Detector DI-9103E: GST Intelligent DI-9000E Series Addressable Heat Detector |
Regulatory: | CE, REACH, RoHS, WEEE compliant CPR, LPCB, EN54-17 certified |
